0.01mm Thick Hvlp Copper Foil , High Temperature Resistant ED Copper Board For Pcb

0.01mm Thick Hvlp Copper Foil , High Temperature Resistant ED Copper Board For Pcb

0.01mm Thick Hvlp Copper Foil , High Temperature Resistant ED Copper Board For Pcb
0.01mm Thick Hvlp Copper Foil , High Temperature Resistant ED Copper Board For Pcb

Büyük resim :  0.01mm Thick Hvlp Copper Foil , High Temperature Resistant ED Copper Board For Pcb En iyi fiyat

Ürün ayrıntıları:

Place of Origin: china
Marka adı: JIMA
Sertifika: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC

Ödeme & teslimat koşulları:

Minimum Order Quantity: 100kg
Fiyat: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Detaylı ürün tanımı
Thickness: 0.01mm Color: red or black
Tensile strength: ≥ 160 MPa Peel strength: ≥ 1 N/mm
Application:: FCCL,FPC
Vurgulamak:

copper foil sheet roll

,

copper sheet plate

High temperature resistance Width 1380mm thickness 0.01mm VLP ED copper foil for PWB



Quickly Introduction.



1) Matte side treatment in back or red.

2) T: 25µm, W:5-1380 mm,standard width:1290mm.

3) internal diameter: 3inch or 6 inch, Length: 500-5000 M.



Products Performance.



a.The perfect physical characteristics of the fine and uniform crystal structure.

B.The very low profile, the high intensity, and high elongation.

c.The high peel strength, no copper powder movement, the clear figure.



VLP ED copper foils application:



1. Communications CCL.

2. Military and other high-power circuit boards.

3. high-frequency board.



RFQ:



Q1. How to save after the box opened?



Keep the dry environment,and is better use it in 30days.



Q2.what is the Internal diameter?



76/152/ custom.



Q3: Can you supply the sample?



We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.



Packaging:



Typical properties of VLP-S-B/R copper foil for FPC or inner layer of HDI.



Classification



Unit Requirement Test Method
Foil Designation /   1 H M 1 IPC-4562A
Nominal thickness / 10um 12um 1/2 OZ (18um) 3/4 OZ(25um) 1 OZ(35um) IPC-4562A
Area Weight g/㎡ 98±4 107±4 153±5 228±8 285±10

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side(Ra) սm ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5

IPC-TM-650

2.3.17

Matte side(Rz) um ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5
Tensile Strength R.T.(23℃) Mpa ≥300 ≥300 ≥300 ≥300 ≥300

IPC-TM-650

2.3.18

H.T.(180℃) Mpa ≥200 ≥200 ≥200 ≥200 ≥200
Elongation R.T.(23℃) ≥4 ≥5 ≥6 ≥8 ≥10

IPC-TM-650

2.3.18

H.T.(180℃) ≥5 ≥6 ≥7 ≥8 ≥8
Peel Strength(FR-4) N/mm ≥0.8

IPC-TM-650

2.4.8

Ibs/in ≥4.6
Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) 180days /
H.T.(200℃) 60 Minutes /



Remark:Standard Width 1295mm,max width 1370(±1)mm,May according to the customer request tailor.We test the peel strength with PI ,please reconfirm with your pp.
