3 / 4 OZ ED Copper Foil Flexible Copper Clad Laminate Good Folding Endurance

3 / 4 OZ ED Copper Foil Flexible Copper Clad Laminate Good Folding Endurance

3 / 4 OZ ED Copper Foil Flexible Copper Clad Laminate Good Folding Endurance
3 / 4 OZ ED Copper Foil Flexible Copper Clad Laminate Good Folding Endurance

Büyük resim :  3 / 4 OZ ED Copper Foil Flexible Copper Clad Laminate Good Folding Endurance En iyi fiyat

Ürün ayrıntıları:

Place of Origin: china
Marka adı: JIMA
Sertifika: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC

Ödeme & teslimat koşulları:

Minimum Order Quantity: 100kg
Fiyat: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Detaylı ürün tanımı
Pinholes: None Thickness: 3/4 oz
Color: red or black Peel strength: ≥ 1 N/mm
Application:: FCCL,FPC
Vurgulamak:

copper foil paper

,

hvlp copper foil

3/4 OZ good folding endurance VLP ED copper foil for Flexible Copper Clad Laminate.





Specifications.



- Matte side treatment low profile foil in back/red.

- Thickness Range: 3/4OZ.

- Width Range: 5-1380 mm.

- Length: 500-5000 M.

- ID: 76 mm,152 mm.

- Cu Content: 99.8%.



Products application:



Casting and lamination type FCCL,Super fine pattern FPC&PWB, Chip on flex (COF) for LED.





Packaging & Delivery.



1. Packaging Details:wooden carton.

2. Delivery Detail:25-30days,depend on quantity.





RFQ:



Q1: Can you supply the sample?



We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.



Q2.is the copper foil Floating in box?



Yes, it is .



Q3: What's your guarantee?



All our products have 6 months guarantee after received goods, if any quality problem can contact us.





Typical properties of VLP-S-B/R copper foil for FPC or inner layer of HDI.



Classification



Unit Requirement Test Method
Foil Designation /   1 H M 1 IPC-4562A
Nominal thickness / 10um 12um 1/2 OZ (18um) 3/4 OZ(25um) 1 OZ(35um) IPC-4562A
Area Weight g/㎡ 98±4 107±4 153±5 228±8 285±10

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side(Ra) սm ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5

IPC-TM-650

2.3.17

Matte side(Rz) um ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5
Tensile Strength R.T.(23℃) Mpa ≥300 ≥300 ≥300 ≥300 ≥300

IPC-TM-650

2.3.18

H.T.(180℃) Mpa ≥200 ≥200 ≥200 ≥200 ≥200
Elongation R.T.(23℃) ≥4 ≥5 ≥6 ≥8 ≥10

IPC-TM-650

2.3.18

H.T.(180℃) ≥5 ≥6 ≥7 ≥8 ≥8
Peel Strength(FR-4) N/mm ≥0.8

IPC-TM-650

2.4.8

Ibs/in ≥4.6
Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) 180days /
H.T.(200℃) 60 Minutes /



Remark:Standard Width 1295(±1) ,max width 1370(±1)mm,May according to the customer request tailor.We test the peel strength with PI ,please reconfirm with your pp.
